Sachet Water Filling Machine

bag water machine

Normal Liquid pouch filling machine

pouch filling machine with photocell monitoring

With photocell monitoring Liquid pouch filling machine

Two type for choice

What’s the difference between photocell monitoring sachet packaging machine and none photocell monitoring water pouch packing machine?

Liquid bag packaging machine is widely used for packaging various liquid, such as pure water,city water, mineral water,spring water, milk, soybean milk, fruit juice, beverage, ice drink, soy sauce, vinegar and wine, etc. The sachet filling machine makes use of a single layer of PE film as packaging materials. The pouch filling machine automatically sterilized by ultraviolet radiation, it is able to precisely fill, seal and cut at one time. The liquid filling machine is easy to operate and run smoothly with good performance and low failure rate.

Photocell monitoring sensors are used to identify the marks on the sachet / pouch printing to make sure each product is in the same look, while the none photocell monitoring can only cut and seal in the preset length.

Technical Parameters

Water Pouch Packing Machine Capacity of Production: 1500~2200B/H
Pouch Packing Machine Packing Volume: 100~500ml/B
Filling precision: ±1%
Bag PE Film width: 240mm or 320mm (optional or choose others)
Motor power: Singel phrase, Three phrases 1.1KW
Vertical hot seal: 0.3KW;
Horizontal hot seal: 0.5KW
UV sterilizer lamp: 1.5KW
Power supply: AC220V/Hz or AC380V(three phrases)
The weight of the Sachet Water Packing Machine: 360kg
Normal Type Sachet Filling Machine Dimension(L×W×H): 750*700*1700mm
Pouch Filling Machines With photocell monitoring type Dimension(L×W×H): 750*700*1700mm

Sachet filling machine with logo


1. Bag (sachet )-forming
2. UV sterilization
3. Thermal vertical sealing
4. Date lamination
5. Linear bag traction
6. quantitative filling
7. Thermal transverse sealing
8. Bag-cutting
9. Automatic counting

How to drink a sachet / pouch product?

how to drink sachet water

Sachet / pouches may be torn open from the corner and poured or a provided straw may be inserted into the sachet / pouch.

Where can I find the source of consumables, say PE film?

bag film of water bagging machine

To save shipping freight, we would recommend our customers to find the PE film locally, but we also offer PE film including printing at a competitive price, and if you are into the most popular sachet / pouch pure/mineral water business, we can also offer you a total solution including the water treatment, sachet / pouch filling machines, packaging plastic material and even factory design. Pls consult our sales engineer for more info.

Invest feedback in Sachet water, Bagged Water, Pouch Water business

sachet water plant

PROFIT $100,000

  • Bag water materials $0.01
  • Bag water sales $0.02-0.10
  • Capacity 5Million psc per year

Sachet filling machine is the most easy water business machine. It only need one machine . Do not like bottled water which need a lot machine machine. It can forming the film into bag and filled water in to the bag at the same time . Once finished then can got an final bag water product.

It is the most simple and easy way to start bag water business. Everything can printing well at the film, when forming bag water, everything like company information and water information is well show outside of the bag water.

1kg film can produce 500psc bag water . And 1kg film cost $3. Average bag water cost $0.006. So that one bag water sell at $0.02 which can still have big profit . Because one day can produce 20000psc bag water with one machine . One machine just cost $1500-2100.

One day can profit $0.014*20000psc=$280 . One year at least profit $84000

Because of big water company only aim big city and big Country. It is have a lot chance and room in some area which lack safe drinking water. And produce pure bag water is the most safe water in the world. Because of the bag water cost is very low, so that most people can easily paid it and will buy. And good quality sachet water can save a lot life and keep people health. Only an small invest in the bag filling machine and water purification machine, but finally will got about $84000 profit per year.

Water purification for produce pure water


RO water purification system is use to produce pure water and supply pure water for sachet filling machine. It make sure the bag water quality and make sure good drink water. It made your sachet water brand good. Most water sachet water packaging plants are in developing countries with a very large percentage of poor people where the living conditions within the countries are relatively low. Most of the time there is very poor or no infrastructure at all resulting in big problems with electricity and water. The electrical problem can be handled with a generator and in order to get water in most cases you will need a deep well or even have water trucked to site. You can start this business in house. But make sure you need an good RO water purification system to make sure the pouch water quality. Ro system also is widely use in purified bottle water plant. It is the high standard.

Benefits of water bagging, pouches or sachet water:

sahet water package

Only affordable way to package water in poorer countries.
Can be very profitable; especially in large volume.
Can have printed bags.
The rolls plastic can be shipped at a very low cost vs. bottles
Much better use of plant space as the units are compact.
More environmentally friendly do to less plastic than bottles
Much lower cost to set up plant for bagging vs. bottles.
Street sellers will sell to create jobs..

How Can We Help?

liquid packaging machine with logo

We specializes manufacturer water purification equipment such as water filtration systems to produce pure water for your sachet plant. We also offer sachet filling machine and water bagging machine that are currently used worldwide. We will assist you with establishing your bagged water purification and packaging plant from the conception of the idea to when you are ready to open your plant. Please call or email us to find out more on this profitable business and to see how Shenzhen Angel can help you start your operation.
